Specifications
Subwoofer Frequency Range: 36 Hz - 500 Hz
Inputs: Dual Coil
Fs: 34.3 Hz
Cutout Diameter: 11 in
BL: 8.859
Nominal Impedance: 4-ohm + 4-ohm
Voice Coil Size: 2 in
Material: Polypropylene
Magnet Size: 140 oz
Sensitivity (1W / 1M): 85.86 dB
Motor Structure: 39 oz
Mounting Depth: 5.875 in
Xmax: 7.9 mm
Spl: 85 dB
No: 0.234%
Qts: 0.682
Qes: 0.763
Qms: 6.429
Mms: 172.7 g
Cms: 125 uM/N
Vas: 46.09 Ltr
SD: 510.7 sqCM
Test Impedance: 1.61 ohm
VC Impedance: 4-ohms
Size: 12"
Sensitivity: 85 dB
Frequency Response: 36 Hz - 500 Hz
Voice Coil Size: 2"
Power Handling (RMS/Peak): 250 / 500 watts
